High current patch rectifier bridge
High current patch rectifier bridge Back
 PDF

Introduction 1, YBS6 packaging adopts environmental protection materials, in line with RoHS standards;
2. SMT rectifier bridge products are suitable for automatic plate loading by customers, replacing the existing bridge stack application built by 4 axial diodes, and effectively improving the efficiency of plate loading by customers;
3, internal packaging PhotoGlass process chip, three layers of passivation protection, stable high temperature characteristics and reliability;
4, the product has a large flow capacity :10A, strong surge capacity :250A, higher reverse voltage :1000V, lower forward voltage drop :1.0V
Features Home appliance market is developing more and more intelligent, miniaturized and flat. TV products are becoming thinner and thinner, and the electronic components used inside also need to be upgraded to a flat direction. In the early stage, our company has successfully launched YBS, YBS3, YBS3mini and other patch rectifier bridge products for mobile phone charger, adapter, TV power supply and other industries, and successfully launched mass production. Our company pays close attention to the development trend of the industry, closely linked with TOP customers, with the development of high current, high voltage, patch rectifier bridge: YBS6 (10A) series products, mainly used in the TV power supply industry.
SPECIFICATION

YBSN100005-THRU-YBSN10010
